小信号MOS产品
特点:
小信号MOS产品系列特点 :高速信号开关，集成ESD功能最高可达8KV MOS 以及0402尺寸最低20毫欧姆以及SOT723N封装最小18毫欧，DFN2*2 5毫欧等超低阻抗MOS
密勒团队在智能硬件领域以及以BYD代表的车载电子应用经验丰富。密勒半导体产品成功应用在手机通讯，智能家居,智能穿戴IOT，无人机，汽车电子，安防照明，电源适配器，网络通信等领域。陆续导入了CVTE,HONOR,NOKIA,ONE-PLUS,小米，传音，倍思，安克，Realme，ZTE,龙旗，Belkin，BYD,JBL,ZKTeco等公司产品
小信号MOS产品选型与推荐表
| N/P | MillerP/N | Assembly | BVdss(V) | ID(A) | Vth(V) | Vgs(V) | Ron(10VmΩ) | Ron(4.5V)mΩ | Ron(2.5V)mΩ | ||||||
| Min | Typ | 25℃ | Min | Typ | Max | Typ | Max | Typ | Max | Typ | Max | ||||
| 12VPMOS | MP12N23 | DFN2*2 | -15 | -16 | -6 | -0.4 | -0.7 | -1.1 | ±10 | 23 | 28 | 40 | 50 | ||
| MP12N23M | DFN2*2 | -17 | -18 | -10 | -0.4 | -0.7 | -1.1 | ±10 | 17 | 25 | 25 | 38 | |||
| MP18T23M | SOT23 | -16 | -18 | -16 | -0.4 | -0.7 | -1.1 | ±10 | 16 | 25 | 21 | 38 | |||
| 16VPMOS | MP16T15MR | SOT23-3 | -16 | -18 | -8 | -0.4 | -0.6 | -1 | ±10 | 15 | 20 | 22 | 38 | ||
| MP16T15MA | SOT23 | -15 | -16 | -8 | -0.4 | -0.6 | -1 | ±10 | 15 | 20 | 22 | 38 | |||
| MP1632 | MLN1212 | -15 | -16 | -3.8 | -0.4 | -0.65 | -1 | ±12 | 37 | 45 | 47 | 60 | |||
| MP16T32MR | SOT23-3 | -15 | -16 | -3.8 | -0.4 | -0.5 | -0.9 | ±10 | 34 | 45 | 44 | 60 | |||
| MP1620 | MLN1212-3 | -16 | -18 | -4 | -0.4 | -0.65 | -1 | ±10 | 21 | 25 | 29 | 35 | |||
| 20V-PMOS | MP20T011 | SOT23 | -20 | -22 | -2.8 | -0.4 | -0.7 | -1 | ±12 | 110 | 130 | 150 | 180 | ||
| MLP2301 | SOT23 | -20 | -22 | -2.8 | -0.4 | -0.7 | -1 | ±12 | 90 | 120 | 110 | 130 | |||
| MP20T38MR | SOT23 | -20 | -22 | -4 | -0.4 | -0.7 | -1 | ±12 | 38 | 50 | 51 | 70 | |||
| MP20N036 | DFN1006 | -20 | -22 | -0.6 | -0.4 | -0.7 | -1 | ±12 | 360 | 500 | 550 | 700 | |||
| MP20N036A | DFN1006 | -20 | -22 | -1 | -0.4 | -0.6 | -1 | ±12 | 310 | 350 | 380 | 450 | |||
| MP20T65MR | SOT23 | -20 | -22 | -2.8 | -0.4 | -0.7 | -1.1 | ±12 | 103 | 140 | 140 | 200 | |||
| MP2053 | MLN1212 | -20 | -22 | -2 | -0.5 | -0.65 | -1 | ±12 | 580 | 650 | 900 | 1200 | |||
| MP2053A | MLN1212 | -20 | -22 | -2 | -0.5 | -0.6 | -1 | ±12 | 290 | 350 | 380 | 450 | |||
| MP20T25MR | SOT-23 | -20 | -22 | -6 | -0.4 | -0.7 | -1.1 | ±12 | 25 | 35 | 38 | 50 | |||
| MP20T25MA | SOT23-3 | -20 | -22 | -6 | -0.5 | -0.6 | -1 | ±12 | 19 | 25 | 24 | 35 | |||
| MP20N18 | DFN2*2-6L | -20 | -22 | -15 | -0.4 | -0.7 | -1 | ±12 | 16 | 19 | 22 | 26 | |||
